Cap Compression Molding Machine

● 16,24,28 Cav. Rotary Bottle Cap Compression Machine
● Output: 1200 pcs/cavity/hr (cap production line)
● More than 45% of plastic(HDPE) beverage caps are produced through compression. Continuous Compression Molding Machine.
● It’s easy to start the machine with one button

● The DMK-CM16,The DMK-CM24,The DMK-CM28 rotary plastic bottle cap compression molding machine(continuous compression molding machine),as the innovation of the second generation of plastic cap molding processing, produces all sizes of both CSD and water caps with high efficiency and quality from PP & PE resin. This fully automatic cap compression molding machine is warmly welcome by customers with the advantages of high output, low consumption and labour saving

● The DMK-CM HDPE cap compression molding machine, completely controlled by computer, has excellent stability and durability. Caps made by this machine have smooth & nice appearance, no injection point and size conformity, comparing with similar traditional injection machine, the output is increased by 3 times, and the usage of raw materials increased up to 98% with environmental production and no hot runner waste. Meantime, this machine saves human labour a lot, decreaseuse of the floor area and finally save energy. Specialrequests from customers like printing marks and logo can also be realized accordingly with low cost and high efficiency

● DMK-CM hydraulic rotary presses are specially designed to produce thermoplastic products by means of compression. A continuous work cycle is carried out, during which the plastic material is fed by a plasticization unit, cut into suitably sized pellets and then inserted inside the cavities. More than 45% of plastic beverage caps are produced through compression.
Max capacity pcs/hr 9000-16000 17000-25000 19000-28000 22000-36000 33000-52000
3025 capacity pcs/hr 16000 25000 28000 36000 52000
38mm capacity pcs/hr 9000 17000 19000 22000 33000
Diameter of cap mm 22-42 22-42 22-42 22-42 22-42
Height of cap mm 10-25 10-25 10-25 10-25 10-25
Number of cavity PCS 16 24 28 36 48
Actual power consumption KW 16-20 28-33 32-35 32-42 50-60
Operating pressure Mpa 0.8 0.8 0.8 0.8 0.8
Pressure consuming M3/hr 2 2 2 2 2
Power supply V/HZ 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ
Machine weight TON 4.5 6.3 6.5 8 11.5
Dimension mm 4300*1750*2600 4800*2180*2600 4800*2180*2600 5300*2180*2600 6100*2180*2600
Installation power KW 40 55 55 95 75

* Demark reserves the right to make changes to the products and specifications are subject to change without notice.
